The new indoor version of the SIXPAR 100(TM) features 12W 6-IN-1 RGBAW+UV LEDs, 100,000 average hour LED life, 15° beam and 25° field angles, electronic strobe and dimming (0-100%), 5 variable dimming curves, dual yoke / floor stand, multiple unit power linking, RDM (Remote Device Management), rugged die-cast aluminum exterior, no fans for silent operation, flicker free operation for TV and Film and a multi-voltage universal auto switching power supply (110-250V).
FEATURES
15° Beam 25° Field Angles
5 Variable Dimming Curve Modes
Dual Yoke / Floor Stand
Multiple Unit Power Linking
RDM - Remote Device Management
Rugged Die-Cast Aluminum Exterior
Flicker Free Operation for TV and Film
SOURCE
(7) 12W 6-in-1 RGBAW+UV LEDs
100,000 Hour Average LED Life*
PHOTOMETRIC DATA
12,850 LUX 1,194 FC @3.3’ (1m) (15° Full ON)
2,880 LUX 268 FC @6.6’ (2m) (15° Full ON)
1,401 LUX 130 FC @9.8’ (3m) (15° Full ON)
848 LUX 79 FC @13.1’ (4m) (15° Full ON)
571 LUX 54 FC @16.5’ (5m) (15° Full ON)
EFFECTS
Electronic Strobe
Color and Chase Macros
Electronic Dimming: 0% - 100%
5 Variable Dimming Curve Modes
CONTROL / CONNECTIONS
(4) DMX Channel Modes (6 / 7 / 8 / 12)
(4) Button Touch Control Panel / LCD Menu Display
3pin & 5pin DMX and powerCON In/Out
SIZE / WEIGHT
Length: 10.1” (257mm)
Width: 4.9” (125mm)
Vertical Height: 9.6” (243mm)
Weight: 7.4 lbs. (3.3 kg)
ELECTRICAL / THERMAL
AC 110-250V - 50/60Hz
89W Max Power Consumption
Power Linking: 12pcs @110V / 25pcs @240V
5°F to 113°F (-15°C to 45°C)
UV Wavelength: 395nm
INCLUDED ITEMS
powerCON Power Cable
*LED Life may vary depending on several factors including but not limited to: Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.
