Madrix 5 professional licence
- Madrix is a powerful, easy-to-use, and award-winning LED lighting control software
- Allows you to realize all kinds of different LED projects and lighting designs
- A normal PC/laptop can be used for professional LED control
- Includes 1 license for the software Madrix
- Provides the output for 128 x 512 DMX channels and 1024 x 1024 DVI voxels (corresponds to 128 DMX universes / 65536 DMX channels and 1048576 DVI voxels)
- The license activates a USB dongle (KEY), with which the software can be operated
- Can be used in parallel with other Madrix licenses
- Can be upgraded to higher licenses (up to Madrix maximum)
- Supports many industry protocols and communication standards for direct connection to your LEDs and LED controllers (incl. DMX512, Art-Net, Streaming ACN (E1.31), Philips Color Kinetics (KiNET), Insta/ROBE protocols, Philips Hue, SPI via Nebula etc.)
- Allows mapping in 2D (pixel mapping) as well as real, spatial 3D (voxel mapping)
- The software generates unique effects, visuals, and animations live and in real time
- No additional content is required
- Already includes a multitude of stock effects that are fully customizable (in speed, color, shape, direction, size, movement, position, brightness, etc.)
- TRI effects will be based on existing Madrix Effects. On top, you can trigger them manually using DMX-IN or MIDI
- The audio output of videos can be put out directly
- CSV fixture list import possible
- Analyzes incoming audio signals Sound2Light and Music2Light in real time
- New lighting scenes can easily be created in seconds
- Supports media server features also: Conveniently load and play back images, pictures, and videos as well as live signal capturing, screen capturing, scrolling text (ticker), and more
- Variety of options to combine visuals and graphical elements (layers, mix modes, filters, etc.)
- 256 x 256 Storage Places to organize and store effects
- DJ-like operation with 2 decks (Left/Right) and a crossfader
- 3 real-time previews to show your visual effects in advance (incl. 2D/3D, zoom, rotation)
- Controls up to 4 color channels per pixel/voxel (e.g. 1-channel, 2-channel, RGB, RGBW fixtures)
- Freely configurable Cue List for automated playback of a show (incl. time, date, duration, etc.)
- Supports Time Code from Art-Net, MIDI, SMPTE, and system time
- Remote control available via DMX-IN, Art-Net Remote, MIDI-IN, HTTP (internet browser), CITP
- Accompanying Fixture Editor provided including large fixture library
- Includes various other tools and features (DMX Fader Tool, DMX Watcher, Matrix Generator, Patch Editor, Touch Screen window, backup system, scripting, mapping, scaling, etc.)
- Supports various 3rd-party interfaces and Madrix hardware interfaces (sold separately)
- Minimum system requirements: 2.0 GHz dual-core CPU, OpenGL 2.0 graphics card (NVIDIA recommended), 2 GB RAM, 1 GB free hard disk space, 1280 x 768 screen resolution, network card, sound card, USB 2.0
- Supported operating systems: Microsoft Windows Vista 7 8 8.1 10 (compatible with 64 bitn only!)
- Installation instructions and software available in English, Spanish, French, and Simplified Chinese
- User manual available in English
- Developed in Germany
- Free software demo version, user manuals, and more information available at www.madrix.com
- Made in Germany
| Dimensions(LxWxH)
( Length × Width × Height ):
|
0,01 × 0,01 × 0,01 cm |
